隆德鏈號

節距

滾子直徑

內節內寬

銷軸直徑

銷軸長度

內鏈板高度

鏈板厚度

其他技術

參數

PDF圖紙

DXF圖紙

P

d1

b1

d2

L

Lc

h2

t/T

max

min

max

max

max

max

mm

mm

mm

mm

mm

mm

mm

mm

*LD25SH-1

6.35

3.3

3.18

2.31

9.0

-

6.0

1.04

請咨詢

請咨詢

請咨詢

*LD35SH-1

9.525

5.08

4.77

3.58

13.3

14.3

9.0

1.50

LD40SH-1

12.70

7.95

7.85

3.96

18.8

19.9

12.0

2.03

LD50SH-1

15.875

10.16

9.40

5.08

22.1

23.4

15.1

2.42

LD60SH-1

19.05

11.91

12.57

5.94

29.2

31.6

18.0

3.25

LD60SH-F1

19.05

11.91

9.50

5.94

25.4

27.6

18.0

3.25

LD80SH-1

25.40

15.88

15.75

7.92

36.2

37.7

24.0

4.00

LD100SH-1

31.75

19.05

18.90

9.53

43.6

46.9

30.0

4.80

LD120SH-1

38.10

22.23

25.22

11.10

53.5

57.5

35.7

5.60

LD140SH-1

44.45

25.4

25.22

12.70

57.6

62.2

41.0

6.40

LD160SH-1

50.80

28.58

31.55

14.27

68.2

73.0

47.8

7.20

LD180SH-1

57.15

35.71

35.48

17.46

75.9

81.6

53.6

8.00

LD200SH-1

63.50

39.68

37.85

19.85

86.6

93.5

60.0

9.50

LD240SH-1

76.20

47.63

47.35

23.81

109.6

115.9

72.3

12.70

LD955SH-1

28.58

21.3

17.46

11.10

46.8

-

30.6

6.40/5.60

#LDC60SH-1

19.05

12.7

11.10

7.11

29.3

-

18.9

4.0/3.25

#LDC63SH-1

19.05

14.29

9.55

7.30

27.9

-

19.6

4.15/3.25

#LDC70SH-1

22.225

15.6

14.30

7.94

36.6

-

22.6

4.80/4.00

#LDC70SH-F1

22.23

15.6

14.30

7.93

35.8

-

23.5

4.8/4.0
